PVC Lay Flat Hose-Heavy Duty
Construction: Blue or any other color pvc layer, Anti Abrasion And UV resistant
Reinforcement: High Density Polyester Yarn
Usage: High Pressure Water Delievery
Safety Factor: 3:1
Temperature: -10℃ To 40℃
Reinforcement: High Density Polyester Yarn
Usage: High Pressure Water Delievery
Safety Factor: 3:1
Temperature: -10℃ To 40℃
| Part No | Size | Work Pressure | Burst Pressure | Weight | Length | |||
| mm | inch | bar | psi | bar | psi | kg/m | meters/roll | |
| FSLH030025 | 25 | 1" | 10 | 150 | 30 | 450 | 0.28 | 30/50/90/100 |
| FSLH030038 | 38 | 1 1/2" | 10 | 150 | 30 | 450 | 0.38 | 30/50/90/100 |
| FSLH030051 | 51 | 2" | 10 | 150 | 30 | 450 | 0.42 | 30/50/90/100 |
| FSLH030064 | 64 | 2 1/2" | 10 | 150 | 30 | 450 | 0.65 | 30/50/90/100 |
| FSLH030076 | 76 | 3" | 10 | 150 | 30 | 450 | 0.76 | 30/50/90/100 |
| FSLH030102 | 102 | 4" | 10 | 150 | 30 | 450 | 1.15 | 30/50/90/100 |
| FSLH030152 | 152 | 6" | 8 | 120 | 24 | 360 | 2.30 | 30/50/90/100 |
