Solid PVC Suction Hose-Heavy Duty
Construction: Solid Color PVC Tube,Smooth Surface
Reinforcement: White PVC Rib Spiral
Usage: Water Delivery And Suction Discharge
Safety Factor: 3:1
Temperature: -10℃ To 40℃
Reinforcement: White PVC Rib Spiral
Usage: Water Delivery And Suction Discharge
Safety Factor: 3:1
Temperature: -10℃ To 40℃
| Part No | Size | Inner Diameter | Outer Diameter | Thickness | Weight | Length |
| inch | mm | mm | mm | kg/m | meters/roll | |
| FSSH03019 | 3/4" | 19 | 26 | 3.5 | 0.32 | 6/15/20/30 |
| FSSH03025 | 1" | 25 | 32 | 3.5 | 0.41 | 6/15/20/30 |
| FSSH03032 | 1 1/4" | 32 | 40 | 4.0 | 0.60 | 6/15/20/30 |
| FSSH03038 | 1 1/2" | 38 | 46 | 4.0 | 0.72 | 6/15/20/30 |
| FSSH03051 | 2" | 50 | 59 | 4.0 | 1.10 | 6/15/20/30 |
| FSSH03064 | 2 1/2" | 63 | 72 | 4.5 | 1.38 | 6/15/20/30 |
| FSSH03076 | 3" | 75 | 85 | 5.0 | 1.80 | 6/15/20/30 |
| FSSH03102 | 4" | 102 | 113 | 5.5 | 2.50 | 6/15/20/30 |
| FSSH03125 | 5" | 125 | 137 | 6.0 | 3.50 | 6/15/20/30 |
| FSSH03150 | 6" | 152 | 168 | 7.0 | 5.50 | 6/15/20/30 |
| FSSH03200 | 8" | 204 | 222 | 9.0 | 7.50 | 6/15/20 |
